SkyLine 4 - Reinforced Drone Power Cable

SkyLine 4 — Reinforced AC Supply Cable (up to 80 m)

SkyLine 4 is the single-phase AC mains/generator supply line for next-generation WasherDrone ground systems. It connects the power source to the skid-mounted ground unit, delivering stable power across long field runs while staying flexible and abrasion-resistant for repeated reel deployment. Available in custom lengths up to 80 m.

Built around a 3G4 construction (3 × 4 mm² fine-stranded annealed copper, L/N/PE) in a heavy-duty H07RN-F class rubber sheath, the cable is rated for continuous outdoor industrial use and supports the ~15 A typical draw of single-phase WasherDrone systems.

Technical specifications

• Conductor: 3 × 4 mm² fine-stranded (Class 5) annealed copper — flexible, low-resistance
• Construction: 3G4 (Line / Neutral / Protective Earth)
• Cable type: heavy-duty rubber-sheathed, H07RN-F class
• Voltage rating: 450/750 V — single-phase only
• Operating temperature: −25 °C to +60 °C
• Jacket: oil-, abrasion- and UV-resistant
• Length: made-to-order, single continuous run up to 80 m (no inline joints)
• Voltage drop: ≈3% at 15 A over 50 m, ≈4.6% at 80 m — within the 5% limit
• Current: matched to the connected system (~15 A typical); derate when fully wound on a reel (heat build-up)
• Plug: Type F (Schuko), 16 A / 250 V
• Connectors: IP-rated industrial plug/coupler
• Certifications: CE; RoHS-compliant

Note: This cable powers single-phase systems only. Three-phase (380 V) systems require the dedicated CEE three-phase supply cable.
